Mechanical Drive Screen Printing Machine On Plastic Wood Ceramics Metal Products
Product Details:
| Place of Origin: | China |
| Brand Name: | Senny |
| Certification: | CE SGS |
| Model Number: | SL1488 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood package |
| Delivery Time: | one month |
| Payment Terms: | T/T |
| Supply Ability: | 10pcs/month |
|
Detail Information |
|||
| Auto Grade: | Fully Automatic | Plate Type: | Screen Printer |
|---|---|---|---|
| Printed Colors: | 1 To 8 | Printing Durability: | High Durability |
| Warranty: | 1 Year | After-Sales Service: | Video Or On-line |
| Highlight: | Metal Products Screen Printing Machine,Ceramics Metal Screen Printing Machine,Plastic Wood Screen Printing Machine |
||
Product Description
Mechanical Drive Screen Printer Train Bottle Screen Printer Lotion Bottles, Cream Jars In Plastic, Wood, Ceramics, Metal
- The SL1466 is suitable for printing UV inks in various colors on plastic round bottles and jars. The machine is easy to operate and has a fast changeover speed.
- Model SL1488 is suitable for printing UV inks in various colors on plastic round, oval and square bottles. This machine is popular for a wide range of applications.
- The machine is modular, with each module including separate screen printing and UV curing functions, and can be linearly connected to achieve an integrated production line of up to 8 colors.
- The machine can be connected to a foil stamping or labeling module to make a multifunctional printing line with screen printing and foil stamping or labeling.
- The bottle feeding conveyor can be connected directly to the bottle making equipment or to an automatic bottle trimmer to replace manual bottle feeding.
- After printing, the discharge can be connected to bagging machine instead of manual bagging.
SAFE EFFIENCY INNOVATIVE
* SL1488/1788 automatic printing machines for screen printing of containers of plastic or other materials with round, oval, square or rectangular cross-section, with centered or off-center necks.
* Shape changeover: 30 minutes per machine, from cylindrical to oval or flat.
* Linear unit structure combinations: up to 8 inline colors are optional.
* Machine is PLC and touch screen operated for easy operation with excellent alarm system.
* Infeed components include: infeed belt and robot hand for side selection.
* Side-selection mainframe is driven by servo motor for rotary dedusting and flame treatment of round containers.
* Flame treatment for round, oval and rectangular containers.
* Pre-positioning device
* Secondary positioning device for printing.
* Electronic lifting device for squeegees
* UV curing by rotation of round containers driven by stepper motors.
* Electronic UV system: device with freely adjustable light (alternative to LED UV curing systems).
* Auxiliary machine part with optional oval and square container sides
* Output parts: robot hand and belt for standing up containers
* CE compliant.
Technical Specifications:
| Specification/Model | SL1466 | SL1488 | SL1788 |
| Printing speed | Up to 85pcs/min | Up to 85pcs/min | Up to 80pcs/min |
| Diameter of round bottle | 20–120mm | 20–120mm | 20–150mm |
| Radius of flat bottle | - - - | 5-250mm | 5-250mm |
| Width of flat bottle | - - - | 20-120mm | 20-120mm |
| Height of bottle | 50–300mm | 50–300mm | 50–300mm |
| Printing length | 300mm | 300mm | 300mm |
| Printing Height | 250m | 250mm | 250mm |
Printing samples
Exihibition Show
With years of development, Senny can provide premium quality automatic screen-printing machine, labelling machine, pad printing machine, hot-stamping machine and other printing packaging and services according to customers' special products and demands.
