OEM Pharmaceutical Silk Screen Printing Machine For Cylindrical Containers
Product Details:
| Place of Origin: | China |
| Brand Name: | Senny |
| Certification: | CE SGS |
| Model Number: | SL1466 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood package |
| Delivery Time: | One Month |
| Payment Terms: | T/T |
| Supply Ability: | 10pcs/month |
|
Detail Information |
|||
| Printed Colors: | 1-12 Colors | Plate Type: | Screen Printer With Hot Stamping |
|---|---|---|---|
| Printing Durability: | High Durability | Warranty: | 1 Year |
| Automatic Grade: | Automatic | Stations: | 1-12 |
| Highlight: | Cylindrical Containers Silk Screen Printing Machine,OEM Silk Screen Printing Machine,Pharmaceutical Silk Screen Printing Machine |
||
Product Description
Round Bottle Fully Automatic Silk Screen Printing Machine For Feeding Bottles, Pharmaceutical, Alcohol And Glass Glue
Fully automatic screen printing machine (1-12 colors) for cylindrical containers: SL1466-1C (12C)
1. Machine features 30 years of professional mechanical design and manufacturing, leading technology; precision mechatronics, high-speed, stable and reliable machine operation; linear combination of modular structure, can achieve up to 12-color integrated production line. Integration of loading, surface treatment, screen printing, UV curing and other functions; simple and convenient man-machine dialogue operation function. Newly designed material safety protection and appearance make the machine simple and generous. Cylindrical containers without bottle holder design and printing function make machine adjustment and transfer faster and more convenient.
2. Applicable industries: cosmetics, daily-use chemicals, food, drugs, health care products, baby products, automotive products, cleaning products, alcohol, glass glue, toys, sporting goods and so on.
3. Scope of application: This machine is suitable for single-color or multi-color screen printing on the surface of cylindrical containers. Container materials include plastic, glass and metal. Containers include cans, bottles, cups, lids and hard tubes.
4. Main functions Speed drive feeding function; robot vacuum directional feeding function; host speed motor drive surface treatment function; electrostatic dust removal function; flame surface treatment function; pre-positioning function; container adjustable pressure inflatable printing function; automatic screen printing function; motorized printing head lifting and lowering function is convenient for screen loading and unloading; screen motorized lifting and lowering is convenient for wiping the screen function; high-intensity U.S. UV lamp curing function (optional LED-UV curing function); cylindrical container through the UV speed motor rotation function; robot vacuum unloading function; unloading speed conveying function. High-strength UV lamp curing function (LED-UV curing function is optional); Cylindrical container through the UV speed motor rotation function; Manipulator vacuum unloading function; Unloading speed control conveyor function.
5. Main Components: importing famous brand components
Technical Specifications:
| Machine running speed | Up to 100pcs/min (printing speed varies from bottles to bottles) |
| Product height | 20-300mm |
| Round bottle diameter | 20-120mm |
| Maximum printing area | length 300* height 200mm |
| Gas supply | 0.15mpa |
| Air pressure requires | 6-7 BAR |
| Voltage requirement | 3-phase 5-wire 380V 50/60Hz |
| Rated power | 7KW(1 color ) * N colors |
| Machine weight | Main machine-1200kgs; Auxiliary machine-1000kgs |
| Machine size |
Main machine-L 2900mm * W 1200mm * H 2000mm(excluding feeding and uploading convey belt) Auxiliary machine-L 1900mm * W 1200mm * H 2000mm |
We have strong OEM and ODM capability. We can manufacture and design according to your requirements. Just share your ideas and we will realize mutual benefits.
We are looking forward to cooperating with domestic and international distributors, you can build your own brand or utilize our brand to expand your business.
