Silicone Cartridge Tube 1-8 Colors Screen Printing Machine Automatic Unscramble Feeding
Product Details:
| Place of Origin: | China |
| Brand Name: | Senny |
| Certification: | CE SGS |
| Model Number: | SL1285-4C |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood package |
| Delivery Time: | One Month |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10pcs/month |
|
Detail Information |
|||
| Automatic Grade: | Fully Automatic | Stations: | 1-8 |
|---|---|---|---|
| Printing Durability: | High Durability | Plate Type: | Screen Printer For Sealant Tubes |
| Printing Speed: | Up To 5000Pcs/Hour | Printed Colors: | 1-6 Colors |
| Highlight: | 8 Colors Screen Printing Machine,Automatic 8 Colors Screen Printing Machine |
||
Product Description
Silicone Cartridge Tube 1-8 Colors Screen Printing Machine Automatic Unscramble Feeding
Technical Specifications:
| Printing Diameter | ∮20mm～∮100mm |
| Max.Printing Area | L250*B200mm |
| Printing Speed | Up to 5000Pcs/Hour |
| Liquefaction supply | 0.15Mpa |
| Air pressure | 5-7 bar |
| Power supply | AC380V 3 Phase 50Hz / 60Hz |
| Rated power | 20KW(4 col) |
Machine Features:
- - This machine is suitable for screen printing various colors of UV ink, hot stamping, labeling and other decorations on round sealing tubes.
- - The machine adopts well-known brand electrical components, touch screen and PLC control system is user friendly and reliable.
- - The machine has a highly customizable modular structure and can be linearly connected to form 1-8 color printing machines.
- - The machine comes standard with screen printing and UV curing modules, and the screen printing function is optionally interchangeable with foil stamping or labeling.
- - Optionally, the machine can be connected to separate modules for hot stamping, labeling, quality inspection, etc., to combine them into one multifunctional press.
Optional Configuration:
- Hot stamping function.
- Labeling function.
- LED-UV curing function.
