50Hz Container CNC Automatic Printing Machine , 70pcs/Min Silk Screen Equipment
Product Details:
| Place of Origin: | China |
| Brand Name: | Senny |
| Certification: | CE SGS |
| Model Number: | SRS1699 SRS1669-RT103CH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood Package |
| Delivery Time: | One Month |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10PCS /Month |
|
Detail Information |
|||
| Automatic Grade: | Automatic | Plate Type: | Screen Printer + Hot Stamping |
|---|---|---|---|
| Printing Durability: | High Durability | Product Shape: | Round Tube |
| Warrenty: | One Year | Printed Colors: | 3 Colors Screen Printing + 1 Col Hot Stamping |
| Highlight: | Container Automatic Printing Machine,Silk Screen Equipment Automatic Printing Machine,70pcs/Min Automatic Printing Machine |
||
Product Description
50Hz Container CNC Automatic Printing Machine , 70pcs/Min Silk Screen Equipment
Application:
SRS1669-RT103CH is a new product for use on plastic or metal materials, with varnishing and three-color screen printing and one-color hot stamping for cosmetic and medical soft tubes.
This equipment is designed with high precision ( tolerance control is less than 0.2mm) !!
Automatic silk screen overprinting and hot stamping, it adope independent servo variable frequency apeed regularting device. The printing speed can reach up to 70pcs/min.
Servo gearless design, faster replacement of fixture, simpler, less vulnerable parts.
Features:
1. Installed with internationally reputed components to drive, controlled by PLC and touch screen to ensure the operation easy and simple.
2. Equipped with various alarming device such as no bottle, low pressure, wrong position for loading, UV overheating etc.
3. PLC and Touch screen from Japan to ensure the operation simple and stable.
4. Optimum design for automatic loading and unloading to make the drive simple, guarantee the machine running stable at high speed.
5. All components are from German, USA and Japan to ensure the machine quality and stability of printing.
6. Three languages such as Chinese, English and Spanish supported.
7. We can customize machine according to the special products.
Technical Specifications
| Model | SRS1669-RT103CH |
| Printing stations | 5(3 screen printing colors, 1 col hot stamping and 1 vanishing) |
| Printing speed | Up to 70pcs/min |
| Max. printing area | L250mm X W160mm |
| Product diameter | 12 - 60mm |
| Product height | 220mm |
| Air presser | 6-7 bar |
| Power | 380V 50/60HZ |
We Senny Printing Equipment Co. Ltd also can design the machine with screen printing, hot stamping, varnishing and labeling functions all-in-one.
