LED UV Curing Jars And Caps 1 Color Screen Printer Machine Printing Speed 60pcs/Min
Product Details:
| Place of Origin: | DONGGUAN GUANGDONG CHINA |
| Brand Name: | SENNY |
| Certification: | CE SGS |
| Model Number: | SR812 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PLYWOOD PACKAGE |
| Delivery Time: | ONE MONTH |
| Payment Terms: | T/T |
| Supply Ability: | 10PCS /Month |
|
Detail Information |
|||
| Printing Colors: | 1 Color | Speed: | Up To 60pcs/minute |
|---|---|---|---|
| Machine Color: | As Pic Or Customized | Warrenty: | 1 Year And Lifetime Technical Support |
| Plate Type: | Screen Printer | ||
| Highlight: | 1 Color Screen Printer Machine,Jars And Caps Screen Printer Machine |
||
Product Description
LED UV Curing Jars and Caps 1-Color Screen Printer Machine Printing Speed 60pcs/min
Round Jar & Cap printing machine.pdf
Machine Application:
This machine is a new type of screen printing machine developed with the concept of "simple and high efficiency". It is specially designed for printing round, oval, square plastic containers, regular glass bottles and other special products. You can freely choose from single colors to multi-color, and can be freely combined. The whole machine adopts mechanical synchronization design, with functions such as surface treatment, automatic alignment, no product no print, screen printing, LED curing, etc., to meet the diversity of current product printing processes, and fully automatic Feeding system is also optional.
It has the advantages of high degree of automation, easy use, high precision, high reliability, low price, and very simple operation and maintenance. It is widely used in the cosmetics industry, alcohol industry, home decoration industry, food industry, etc.
Technical specification:
| Max. speed | 3600Pcs/Hour |
| Max. printing area (L × W) | 300mm×100mm |
| Printing product diameter | Φ20~Φ100mm |
| Printing product height | 10~100mm |
| Power requirements (one) | 440V 3 P 60Hz 5KVA |
| Compressed air pressure | 6-7Bar 100L/Min |
| Gas Pressure | 0.8-2Bar |
| Main motor power | 0.75KVA |
| Gearbox ratio | 1:20 |
| LED lamp power | 1KVA |
| Machine size (L x W x H) | 1600mm×1200mm×1800mm |
| Approximate weight (including conveyor) | 1100kg |
