OEM Pharmaceutical Silk Screen Printing Machine For Cylindrical Containers
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | SENNY |
| Certification: | CE SGS |
| Model Number: | SL1466 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood package |
| Delivery Time: | one month |
| Payment Terms: | TT or LC |
| Supply Ability: | 10pcs/month |
|
Detail Information |
|||
| Auto Grade: | Fully Automatic | Stations: | 1-12 |
|---|---|---|---|
| Plate Type: | Screen Printer With Hot Stamping | After-sales Service: | Video Or On-line |
| Printed Colors: | 1 To 12 | Brand: | Senny Or OEM |
| Highlight: | OEM Silk Screen Printing Machine,Pharmaceutical Silk Screen Printing Machine,Cylindrical Containers Silk Screen Printer |
||
Product Description
Round Bottle Fully Automatic Silk Screen Printing Machine For Feeding Bottles, Pharmaceutical, Alcohol And Glass Glue
Fully automatic screen printing machine (1-12 colors) for cylindrical containers: SL1466-1C (12C)
1. Machine features: 30 years of professional mechanical design and manufacturing with leading technology; Precision mechatronics, high-speed, stable and reliable machine operation; Linear combined module structure can realize up to 12 color integrated production line. The machine integrates the functions of feeding and uploading materials, surface treatment, screen printing and UV curing; Simple and convenient man-machine dialogue operation function. The newly designed material safety protection and appearance makes the machine simple and elegant. The cylindrical container without bottle holder design and printing function, which makes the machine adjustment and transfer more quickly and easily.
2. Applicable industries: cosmetic, daily chemical, food, pharmaceutical, health products, baby products, automotive supplies, cleaning supplies , alcohol, glass glue, toy, sporting goods and so on.
3. Scope of application: This machine is suitable for single color or multi-color screen printing on the surface of cylindrical containers. Container materials include plastic, glass and metal, etc. Containers include cans, bottles, cups, caps and hard tubes, etc.
4. Main functions: Speed transmission feeding function; Vacuum directional feeding function of manipulator; Main engine speed regulating motor drive surface treatment function; Electrostatic dust removal function; Flame surface treatment function; Prepositioning function; Adjustable pressure inflatable printing function in the container; Automatic screen printing function; Electric printing head lifting function is convenient for screen loading and unloading; Screen electric lift easy to wipe the screen function; High strength American UV lamp curing function(LED-UV curing fuction can be optional); Speed regulating motor rotation function when cylindrical containers passing through the UV; Manipulator vacuum discharging function; Discharging speed control conveying function.
5. Main Components: importing famous brand components
Technical Specifications:
| Machine running speed | Up to 100pcs/min (printing speed varies from bottles to bottles) |
| Product height | 20-300mm |
| Round bottle diameter | 20-120mm |
| Maximum printing area | length 300* height 200mm |
| Gas supply | 0.15mpa |
| Air pressure requires | 6-7 BAR |
| Voltage requirement | 3-phase 5-wire 380V 50/60Hz |
| Rated power | 7KW(1 color ) * N colors |
| Machine weight | Main machine-1200kgs; Auxiliary machine-1000kgs |
| Machine size |
Main machine-L 2900mm * W 1200mm * H 2000mm(excluding feeding and uploading convey belt) Auxiliary machine-L 1900mm * W 1200mm * H 2000mm |
We have strong OEM and ODM capacity. We can manufacture and design according to your requirements. Just share your ideas, we will achieve mutual benefit.
We are looking forward to cooperate with the domestic and overseas distributors.You can build up you brand or use ours to expand your businees.
